Service (Layer)

Previous Next

A deployable unit composed of modules, wired into an Environment.

What is a Layer/Service?

Services let you manage app-specific resources separately from the shared foundation. They reference an Environment and define the modules they need (databases, queues, buckets, IAM, charts), with per-environment overrides.

flowchart TB svc[(service.yaml)] subgraph PROD[Production Env] prod_service[Service A] end subgraph STAGE[Staging Env] stage_service[Service A] end env[(env.yaml)] svc --> prod_service svc --> stage_service prod_service --> env stage_service --> env

Definition (example)

Based on a typical service spec:

apiVersion: platform.io/v1
kind: Service

metadata:
  name: payments-api
  ref: ./env.yaml
  envRef:
    prod: {}
secrets:
  api_key:
    key: api_key
variables:
  db_name: "testing"
modules:
  - id: postgres
    type: aws_postgres
    inputs:
      database_name: "${var.db_name}"
  - id: s3
    type: aws_s3
    inputs:
      bucket_name: "pltf-app-${layer_name}-${env_name}"
    links:
      readWrite:
        - adminpltfrole
        - userpltfrole
  - id: topic
    type: aws_sns
    inputs:
      sqs_subscribers:
        - "${module.notifcationsQueue.queue_arn}"
    links:
      read: adminpltfrole
  - id: notifcationsQueue
    type: aws_sqs
    inputs:
      fifo: false
    links:
      readWrite: adminpltfrole
  - id: schedulesQueue
    type: aws_sqs
    inputs:
      fifo: false
    links:
      readWrite: adminpltfrole
  - id: adminpltfrole
    type: aws_iam_role
    inputs:
      extra_iam_policies:
        - "arn:aws:iam::aws:policy/CloudWatchEventsFullAccess"
      allowed_k8s_services:
        - namespace: "*"
          service_name: "*"
  - id: userpltfrole
    type: aws_iam_role
    inputs:
      extra_iam_policies:
        - "arn:aws:iam::aws:policy/CloudWatchEventsFullAccess"
      allowed_k8s_services:
        - namespace: "*"
          service_name: "*"
# Add helm chart modules

Notes

  • ${layer_name} comes from the service name; ${env_name} is the selected environment key.
  • links let modules consume other module outputs (e.g., queue ARNs, IAM roles) without manual interpolation.
  • envRef selects envs only; variables and secrets live at the top level.

When to use Services

  • Isolate app stacks (DB + queues + roles) from the shared environment.
  • Share one Environment across multiple Services without duplicating YAML.
  • Enable per-team or per-PR stacks while keeping consistent wiring.
